Titanium Clad Copper Busbar

Group Electroplating and Copper recovery industry
Min. Order 1 kilogram
Terms of Payment L/C, T/T
Update Time 2017-08-08
  • Description
  • Product review
       Baoji steel titanium industry limited liability company leading products for metal composite materials. Include titanium clad copper, zirconium clad copper, stainless steel clad Copper, three metal composite and composite silk material etc series products. Its main feature is in copper, aluminum etc conductive metal bar, platoon, generatrix and silk material outside compound titanium, zirconium, nickel, stainless steel corrosion metal layer. Not only ensure material superior conductivity, and with a strong surface corrosion resistance. Widely used in strong corrosion condition of conductive body, such as electrochemical, electroplating, electrolysis, hydrometallurgy, PCB, electric chemical industry, water treatment, ocean engineering, etc.
Our company since 2001 start manufacture metal composite material series product, after 15 years of hard work development, we have set up a perfect specialized metal composite material production line.
Reference standard GB/T 12769-2003
Specification variety range:
Substrate materials: Copper T1, T2, anaerobic Copper TU1 TU2, Aluminum etc.
The clad materias: Titanium Ti, Zirconium Zr, Nickel Ni, Tantalum Tan, stainless steel (304, 316L), etc.
clad material layer thickness: conventional 1.0 ~ 2.5 mm
Main cross-section shape and size range (mm) :
Rectangular width (20 ~ 150) x thickness (6 ~ 30)
Circle Φ (8 ~ 50)
Square model  (10 ~ 30)
Silk material Φ (2.0 ~ 8.0)
